恒温器
实验室冷却水和热水供应
是实验室及各种实验用的冷却、加热供水系统。使用由热电模块制成的系统
| Items | Details | ||||
|---|---|---|---|---|---|
| General | Part Name | FU-CH-300WH | FU-CH-1000WH | FU-CH-1700WH | |
| Installation | In and out door | ||||
| Ambient temperature | 0 ～ 50 Celsius(℃) | ||||
| Ambient humidity | 40 ～ 80 % RH | ||||
| Power specifications | AC Free Volt | ||||
| Adjustment range | 5 ℃ ~ 70℃ | ||||
| Temperature precision | ± 0.2 ℃ | ||||
| Electrical | Operation(EASY Handling) | Manual Botton | |||
| By PC Program | watt | 400 | 1000 | 1670 | |
| Btu / hour | 1,365 | 3,413 | 5,700 | ||
| Kcal / hour | 335 | 838 | 1,400 | ||
| HEATING POWER | 1 Kw | 2 Kw | 2 Kw | ||
| Input Power | AC Free Volt | ||||
| Temp Control | Full Auto | ||||
| Safety | over voltage protection device | ||||
| Alarm for leckage of coolant | Lighting and alarm when coolant is insufficient | ||||
| others | current temperature | Display | |||
| target temperature | TURN ON WITH START BOTTON | ||||
| cooling fluid | R 410 A | ||||
| pump power | 0.05KW | ||||
| maximum lift | 12M | ||||
| water output amount | 19L/min | ||||
| water tank capacity | 7L | ||||
| others | body color | Ivory, yellow | |||
| weight | 30 Kg | ||||
| Dimension | 55*28*43cm(L*W*H) | ||||
| coolant tank level | Can be checked with the view level scale | ||||
